Our special lubricating light series is a benzene-free and ketone-free surface printing ink, which can be classified into tactile oil-removing gloss, matte oil-removing gloss and anti-slip vanish according to application scenarios.
Detailed
Our special lubricating light series is a benzene-free and ketone-free surface printing ink, which can be classified into tactile oil-removing gloss, matte oil-removing gloss and anti-slip vanish according to application scenarios.
Product uses and features
|
product name |
Applicable substrate |
Single/double liquid |
features |
Packaging classification |
|
PCA 037 touching feel oil-removing gloss |
PET |
Double liquid |
good touch and drying effect |
food, packaging for daily necessities |
|
PCA 307 series scrub vanish |
PET |
Double liquid |
feel effect of sand surface |
food, packaging for daily necessities |
|
TW 103 touching feel oil-removing gloss(water based) |
PET, paper |
Double liquid |
excellent tactile effect |
food, packaging for daily necessities |
|
PCA 077 anti-slip vanish |
OPP, PE(treated) |
Double liquid |
stacked without sliding, high friction |
food, packaging for daily necessities |
Diluent and printing viscosity
1.solvent type
|
Fast-drying solvent |
2-N-BUTOXYETHYL METHACRYLATE/ Isopropyl alcohol=80/20 |
|
|
medium drying |
N-propyl ester/Isopropyl alcohol=80/20 |
|
2.water based
|
medium drying |
Water/Ethanol=80/20 |
Printing viscosity: suggested 18-25s/3# Chain Cup
Instructions for the Use of Curing agent
Curing agent: PCA 90 curing agent or PCA 100 curing agent (solvent-based)
HD 250 curing agent (water-based type) dosage: 6-7%
Performance improvement: Enhanced wear resistance, scratch resistance, temperature resistance, adhesion, etc
Disposal of old ink: Leftover ink with added curing agent should not be stored for a long time. When using it again, it needs to be mixed with new ink and the curing agent should be added again. Pay attention to anti-sticking.
Maturation conditions
Low-temperature curing (25℃ to 35℃) for 8 to 12 hours after printing. Then recombine (to prevent the printed matter from sticking back);
After compounding, cure at 45℃ to 50℃ for 48 hours or more.
Notes
1. After adding the curing agent to vanish, it will gradually react over time. Suggestion: a) Do not add the curing agent at the beginning of machine adjustment, and add it only after formal printing. b) vanish that has been added with curing agent will have the agent consumed due to long-term storage even if it is not used. If the storage time exceeds 3 hours, the curing agent needs to be added again before use.
c)Avoid using old ink that has been added with curing agent. Under normal conditions, it is recommended to use it up within 3 hours.
2.The material of the base film and the surface treatment degree have a significant impact on adhesion. Before printing, it is necessary to confirm whether the adhesion can meet the product requirements.
3.It is recommended that the printing unit be dried at high temperature (60 to 80℃, and the air volume be increased as much as possible) during printing. Cooling treatment should be carried out before winding.
Environmental protection regulations
1Complies with the requirements of regulations such as GB4806.14, GB4806.1, and GB31603;
2.Complies with the requirements of regulations such as ROHs, REACH, and EN71-3.
3.Complies with QB/T 1046 "Surface Printing Inks for Gravure Plastic Films".
4.This product complies with the NL rules formulated by the Japan Printing Ink Association.
