Our varnish series is a benzene-free and ketone-free protective varnish, featuring excellent gloss, wear resistance and temperature resistance. Some products also have certain solvent resistance.
Detailed
Our varnish series is a benzene-free and ketone-free protective varnish, featuring excellent gloss, wear resistance and temperature resistance. Some products also have certain solvent resistance.
Product uses and features
|
product name |
Applicable substrate |
Single/double liquid |
Temperature resistance (0.2MPa/1s) |
Application features |
|
PCA 211 vanish |
PE |
Single liquid |
140-160℃ |
Applications of ultra-high gloss |
|
PJF 01 vanish |
OPP |
Single liquid |
—— |
Extrusion coating, used to enhance extrusion strength |
|
PAN 201 vanish ★ |
OPP , PET, paper |
Single liquid |
160-180℃ |
Universal mask vanish, increase temperature resistance |
|
PCA 218 vanish |
PE(treated) |
Double liquid |
200℃ |
Single material PE, paper heat-resistant application |
|
RKT cover vanish★ |
PP , PET, paper |
Double liquid |
200℃ |
Heat-resistant sealing at high temperatures has certain solvent resistance |
|
TW 003 vanish(water based) |
PET, paper |
Single/double liquid |
200℃ |
Enhance the gloss, heat resistance and wear resistance of the ink layer |
|
TW Q203Heat-sealed vanish(water based) |
PE , PP |
Single liquid |
130-140 |
It can be directly heat-sealed at low temperatures for food packaging such as chocolate. |
Diluent and printing viscosity
1.Solvent type
|
Fast-drying solvent |
2-N-BUTOXYETHYL METHACRYLATE/ Isopropyl alcohol=80/20 |
|
medium drying |
N-propyl ester/Isopropyl alcohol=80/20 |
2.Water based
|
medium drying |
Water/Ethanol=80/20 |
Printing viscosity: 15~30 s ※ 3#Charn Cup
The ratio of Printing viscosity and diluent can be adjusted accordingly according to the printing pattern, drying capacity, printing speed and printing effect.
Instructions for the Use of Curing agent
Curing agent: TCS-4394/PCA 100. Curing agent addition amount: 2-6%
Performance improvement: Enhanced wear resistance, scratch resistance, temperature resistance, adhesion, etc
Disposal of old ink: Leftover ink with added curing agent should not be left for a long time. When using it again, it needs to be mixed with new ink and the curing agent should be added again. Attention should be paid to reverse adhesion.
Maturation conditions
Low-temperature curing (25℃ to 35℃) for 8 to 12 hours after printing. Then recombine (to prevent the printed matter from sticking back);
After compounding, cure at 45℃ to 50℃ for 48 hours or more.
Notes
1. Due to the influence of different substrates, please confirm the adhesion before use.
2.. It is recommended that the printing unit be dried at high temperature during printing and cooled before winding.
3.. The storage environment for the product should avoid excessively high temperatures and excessive pressure.
Environmental protection regulations
1Complies with the requirements of regulations such as GB4806.14, GB4806.1, and GB31603;
2.Complies with the requirements of regulations such as ROHs, REACH, and EN71-3.
3.Complies with QB/T 1046 "Surface Printing Inks for Gravure Plastic Films".
4.This product complies with the NL rules formulated by the Japan Printing Ink Association.
Product application cases
|
Packaging classification |
Specific examples |
|
Daily necessities |
Wet wipes, toy outsourcing, etc |
|
Food packaging |
Nuts, bread, sandwich packaging bags, etc |
